2.06 Inch AMOLED Display 410×502 HD High Brightness Screen for CCD Cameras Smartphone Secondary Displays and Mirrorless Cameras

2.06 Inch AMOLED Display 410×502 HD High Brightness Screen for CCD Cameras Smartphone Secondary Displays and Mirrorless Cameras

$12.49 USD
$12.49 USD
Sale Sold out
ET020AM04-H
For product datasheet and technical support, welcome to contact us at support@youritech.com;
Regarding project mass production needs, please share the FORECAST to info@youritech.com for receiving volume discount pricing.
View full details

Product Introduction


2.06 Inch AMOLED Display Overview

ET020AM04-H is a 2.06-inch AMOLED display featuring a resolution of 410(RGB)×502, delivering sharp and vivid images with a pixel density of 314 PPI. It has an active area of 33.0870(H)×40.5114(V) mm and an overall module dimension of 34.787(H)×43.135(V)×0.8(T) mm, making it suitable for compact display applications. ET020AM04-H offers a typical brightness of 700 cd/m² and a contrast ratio of 60000:1, providing excellent image clarity and deep blacks. With support for 16.7 million colors, a 100% color gamut, and a full viewing angle, this AMOLED display delivers rich, lifelike color reproduction from multiple viewing directions. Its pixel pitch is 0.0807 mm, and it utilizes an SPI interface with a snap-fit connector for signal transmission. The display is driven by the C05300 driver IC and operates with a supply voltage of 2.8–3.3 V. Designed for demanding environments, ET020AM04-H supports an operating temperature range of -30°C to 70°C and a storage temperature range of -40°C to 80°C. It is ideal for compact electronic devices, camera displays, smartphone secondary screens, and other embedded display applications.


ET020AM04-H AMOLED Display Specifications

Parameter Specification Parameter Specification
Part No. ET020AM04-H Size 2.06 Inch
Display Type AMOLED Resolution 410 × 502
Active Area 33.0870(H) × 40.5114(V) mm Module Dimensions 34.787(H) × 43.135(V) × 0.8(T) mm
Pixel Pitch 0.0807 mm Pixel Density 314 PPI
Display Colors 16.7M Color Gamut 100%
Viewing Angle All Directions Contrast Ratio 60000:1
Brightness 700 nits Panel Interface SPI
Connector Type Snap-fit Connector Driver IC C05300
Supply Voltage 2.8–3.3 V Operating Temperature -30°C to 70°C
Storage Temperature -40°C to 80°C
