4.1 Inch AMOLED Display 568×1232 LTPS MIPI OLED Display

4.1 Inch AMOLED Display 568×1232 LTPS MIPI OLED Display

$43.37 USD
$43.37 USD
Sale Sold out
ET041AM01-KT
For product datasheet and technical support, welcome to contact us at support@youritech.com;
Regarding project mass production needs, please share the FORECAST to info@youritech.com for receiving volume discount pricing.
View full details

Product Introduction


4.1 Inch AMOLED Display Overview
ET041AM01-KT supports a display resolution of 568×1232 with an aspect ratio of approximately 1:2.17 (W:H), delivering clear images and fine details. As for mechanical details, it features an active area of 43.85(W)×94.77(H) mm, a display area of 43.55(W)×94.47(H) mm, and an outline size of 48.24(W)×100.84(H)×2.64(D) mm. ET041AM01-KT provides 280 cd/m² display brightness, a 100% color gamut, and full viewing angles, presenting 16.7M colors for vivid image reproduction. This product utilizes LTPS AMOLED technology, allowing each pixel to emit its own light for clear images and rich colors. ET041AM01-KT uses MIPI as its display signal input interface and features an RM69A10 driver IC, a 30-pin plug-in connection, and a GT9895 touch controller IC. It operates at 3.3V and supports an operating temperature range of -20°C to +70°C and a storage temperature range of -30°C to +80°C. Its rated lifetime is 30,000 hours.

Model ET041AM01-KT  4.1 Inch AMOLED Display 568×1232 LTPS MIPI OLED Display
Display Mode AMOLED Display Color 16.7M
Color Gamut 100% Resolution 568x1232
Dot Pitch 0.07668(H)*0.07668(V) Viewing Angle All viewing angle
Driver IC RM69A10 Outline Dimension 48.24*100.84*2.64mm
Active Area 43.85*94.77mm Dot Area 43.55*94.47mm
Brightness 280cd/m² Interface MIPI
Pin Count 30 Touch IC GT9895
Connection Type Plug-in type Operating Voltage 3.3V
Operating Life 30000h Operating Temperature -20℃～+70℃
Storage Temperature -30℃～+80℃


AMOLED Displays Technology

YOURITECH. Comprehensive Manufacturing of  Touchscreen, Driver Board Options

Youritech Driver Board
Youritech's R&D team provides experienced display panel motherboard solutions including industrial-grade driver boards,manufacturing and designing industry-standard TTL/LVDS interface/CON driver boards, LCD driver boards/LCD inverters/EDP driver boards/4K driver boards,industrial displays solutions.

Youritech Production and Manufacturing



Customization & Manufacturing

We support customize and manufacturing based on your requirements,look forward to your contact if you need mass production or design, quick technical support and competitive price will be provided.

Quality is constant

Diligence, processes, and attention to detail are at the core of our business. Our operational framework is built on the 4Cs:
four pillars of quality that underpin our role as the world’s leading display panel designer and manufacturer.

SHIPPING & DELIVERY FAQS

1. Where is my product ship from?
All of products are shipped from China/HK.

2. How long will it take for my order to arrive?
It depends on the shipping method you choose, if you have requirements for the delivery time, please choose the fastest delivery shipping method (DHL).

3. When my order will be shipped out?
Normally, displays take 2–5 days and the HDMI/Demo board takes 1–2 weeks because it needs to be fully tested and configured. If stock is sufficient, we will ship immediately.

4. What`re the function of HDMI board and demo board?
The HDMI board converts HDMI input into the panel's native signal (MIPI/eDP/LVDS), provides power rails and backlight control, it typically doesn`t have touch functionality unless the SKU indicates.
The demo board is a development tool for quickly lighting up and evaluating a display.
