COM43H4M86UTC Ortustech 4.3 Inch TFT LCD Display 480×800 Parallel RGB Transflective Sunlight Readable LCD Panel With 4-wire Resistive Touch

COM43H4M86UTC Ortustech 4.3 Inch TFT LCD Display 480×800 Parallel RGB Transflective Sunlight Readable LCD Panel With 4-wire Resistive Touch

$144.58 USD
$144.58 USD
Sale Sold out
For product datasheet and technical support, welcome to contact us at support@youritech.com;
Regarding project mass production needs, please share the FORECAST to info@youritech.com for receiving volume discount pricing.
View full details

Product Introduction

COM43H4M86UTC Overview
COM43H4M86UTC is a 4.3 inch diagonal a-Si TFT-LCD display screen product, with an incorporated WLED lighting system, without backlight driver, touchscreen 4-wire Resistive Touch.COM43H4M86UTC supports display 480(RGB)×800 (WVGA) with aspect ratio of 3:5 (W:H), whose pixels are arranged in RGB Vertical Stripe. As for mechanical detail, it features active area of 55.8(W)×93(H) mm, outline size of 63(W)×105.3(H)×5.8(D) mm, with surface treament of Clear, Hard coating (3H), net weight of 53.1g. As a VA, Normally Black, Transflective LCM product, COM43H4M86UTC can provides 320 cd/m² display brightness 600:1 transimissive contrast ratio, 1.5:1 (Typ.) reflective contrast ratio, 80/80/80/80 (Typ.)(CR≥10) (L/R/U/D) viewing angle, best view direction on Symmetry , and response time of 40/60 (Max.)(Tr/Td) ms. Gray scale or the brightness of the sub-pixel is determined with a 6-bit gray scale signal for each dot, thus presenting a palette of 262K colors. This product adopted 7S1P WLED as it's backlight systerm which was placed as Edge light type and have a working life time of 50K hours, external backlight driver is additionally needed. COM43H4M86UTC utilizes Parallel RGB (1 ch, 6-bit) as it's signal inputting systerm, which connected by 39 pins FPC with power supply voltage of 1.8/3.0V (Typ.)(VCCIO/VDD). It's typical vertical frame rate (Fv) is 60Hz.

COM43H4M86UTC Application
For Handheld & PDA,Industrial.
COM43H4M86UTC  Specification

Part No. COM43H4M86UTC Size 4.3 inch
Resolution 480 × 800 Display Mode VA, Transflective
Panel Interface Parallel RGB (1 ch, 6-bit) Touch Panel Yes
Outline Dimension 63 × 105.3 mm Active Area 55.8 × 93 mm
Viewing Angle 80/80/80/80 (Typ.) Brightness 320 cd/m² (Typ.)
Operation Temp. -20 ~ 70°C Storage Temp. -30 ~ 80°C
