LQ125T1JW02 Sharp 12.5 inch 2560x1440 RGB LVDS TFT LCD Display Module For Laptop

LQ125T1JW02 Sharp 12.5 inch 2560x1440 RGB LVDS TFT LCD Display Module For Laptop

$61.00 USD
$80.00 USD $61.00 USD
Sale Sold out


LQ125T1JW02 Sharp 12.5 inch 2560x1440 RGB LVDS TFT LCD Display Module For Laptop



Product size
12.5-inch
Type
Oxide TFT-LCD, LCM
Pixel Format
2560(RGB)×1440 [Quad-HD] 235PPI
Configuration
RGB Vertical Stripe
Active Area
276.48(H)×155.52(V) mm
Outline Dim.
282.68(H)×178.66(V) ×2.3(D) mm
Bezel Area
-
Treatment
Antiglare, Hard coating (2H)
Luminance
340 cd/m² (Typ.)
Contrast Ratio
1000:1 (Typ.) (TM)
View Direction
Symmetry
Response Time
25 (Typ.)(Tr+Td)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Operating Mode
IPS, Normally Black, Transmissive
Support Color
16.7M 72% NTSC
Light Source
WLED , 15K hours , With LED Driver
Weight
Slim (PCBA Flat, T≤3.2mm)
Designed For
Laptop
Frequency
60Hz
Touch Panel
Without
Interface Type
eDP (4 Lanes) , 40 pins Connector
Power Supply
3.3V (Typ.)
Environment
Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
For product datasheet and technical support, welcome to contact us at support@youritech.com;
We support customize and manufacturing based on your requirements,look forward to your contact if you need mass production or design, quick technical support and competitive price will be provided.
