LS029B3SX06A Sharp 2.9 Inch LCD Display 2160x2160 MIPI LCD Panel For HMD AR VR

Overview
LS029B3SX06A is a 2.9 inch diagonal CG-Silicon display screen product from Sharp, with a built-in WLED backlight, without backlight driver, without touch screen. LS029B3SX06A supports display 2160(RGB)×2160 with aspect ratio of 1:1 (W:H), whose pixels are arranged in RGB Vertical Stripe, according to calculation of Panelook it's pixel density is 1058 PPI. It features active area of 51.84(W)×51.84(H) mm, outline size of 54.24(W)×59.32(H)×1.52(D) mm, net weight of 7.80g (Typ.). As a SFR, Normally Black, Transmissive LCM product, LS029B3SX06A can provides 100 cd/m² display brightness 700:1 transimissive contrast ratio, best view direction on Symmetry , and response time of 3/5.3 (Typ.)(Tr/Td) ms.

Feature
-sRGB
-WLED Backlight
-Display Colors:16.7M (8-bit)

Screen Size:2.9 inch
Resolution:2160x2160
Brand:Sharp
LS029B3SX06A Sharp 2.9 Inch 2160x2160 LCD Display

What's included in the package ?
-LS029B3SX06A
Application
For HMD AR VR & Industrial LCD

Datasheet & Technical Support
For product datasheet and technical support, welcome to contact us at support@youritech.com;
We support customize and manufacturing based on your requirements,look forward to your contact if you need mass production or design, quick technical support and competitive price will be provided.
